Buffer 100FS
B
-
Storage volume V104 l
-
Height940 mm
-
DiameterΦ500 mm
-
Working pressure10 MPa (bar)
High quality insulation
Technical properties
Characteristics
Energy efficiency class
B
Standing loss S
49 W
Storage volume V
104 l
Dimensions of connections
Height
940 mm
Diameter
Φ500 mm
Heating water inlet
G1 1/4
Heating water outlet
G1 1/4
Net/gross weight/with water
31/33 kg
Technical characteristics
Working pressure
10 MPa (bar)
Max. water temperature
95 °C
Minimalna temperatura vode (hlajenje)
5 °C
Non-enameled steel tank
+
Average thickness of insulation
40 mm
Accessories
Air vent pot with valve G ½
+
Discharge ball valve G ½
+
Plug G1 1/4-ZN 2 pcs
+
Transpotration data
Packaging dimensions [WxDxH]
600x600x1050 mm
